Sold Industrial Property (GA001616)

1988 / 2001
1988 - 63,684 s.f.
2001 - 67,200 s.f.

Excellent

6,084 SF
Features include a lobby/administration, numerous offices, a bullpen area, computer room, storeroom & cafeteria

240' x 240' & 280' x 240' With offsets

Min: 22', Max: 25'

22' - Original
22' - 25' - Addition

40' x 40'

Steel I beam
Original: (2) bays at 40' x 39'3"
Addition: (2) bays at 40' x 50'

Original:
Lightweight concrete deck with a membrane covering

Addition:
Single-ply membrane over 1/2" protection board over 2" rigid insulation over a metal deck
Office: Standing seam metal

6" and 7" reinforced concrete with a 6 mil. vapor barrier, min. 3,000 psi slab with "fibermesh" reinforcement

Original portion including the office area features brick exterior walls over block - the addition is tilt-up concrete

400 watt metal halide fixtures in the production/warehouse areas and 400 watt outside perimeter fixtures, perimeter mounted windows in place throughout addition

East wall:
7 - 8' x 10' tailgate manually operated, all with bumpers, seals and lights, all have levelers (some hydraulic, some manual)
1 - 14' x 16' tailgate, electrically operated with hydraulic leveler
1 - 14' x 16' ramped drive in, electrically operated

West wall:
1 - 14' x 16' drive in, electrically operated

160 paved, marked & lighted spaces

City - 6" main, 300 lb. pressure, 3" line

City (MEAG)
Original:
Secondary: 277/480V, 3-phase, 4-wire & 4,000 amp Square D switchgear

Transformer: Section is currently disconnected from any transformer

Note: A separate 240 kva interior transformer served a small section of this building for the process equipment

Distribution: Buss duct, 120’ @ 600 amps

Addition:
Secondary: 277/480V, 3 phase, 4 wire & (5) 4,000amp Cutler Hammer switchgear

Transformer: (5) 2,500 kva pad mounted

Distribution: Buss duct, 120’ @ 600 amps

Yes - Original:
Roof top mounted Trane combination heating and air-conditioning units; (9) 25-ton units service the manufacturing/warehouse area; (1) 15-ton unit serves the office area and (1) 7.5-ton unit serves the mezzanine/office area

Addition:
Roof top mounted Trane units with (11) 20-ton units for air-conditioning; (8) 20-ton units are combination heating and air-conditioning and (2) 7.5-ton units are combination heating and air-conditioning

Yes - 100% wet system

Original:
(2) 4" risers - (1) at .15 gpm over remote 2,000 SF (office) & (1) at .2 gpm over remote 3,000 SF (mfg/whse)

Addition:
(2) 4" risers

Wall fans & louvers

Air lines located throughout the manufacturing/warehouse areas, compressors have been removed

- MEAG (power co.) substation adjoins property
- 3,960 SF of mezzanine area not included in total s.f.
- Building is fenced with guard house controlling ingress and egress

Mfg. rubber & plastics
