Sold Industrial Property (NC002861)

1996

Excellent

7,000 SF
Approximately 7,000 square feet of office and plant support areas including a lobby and reception area, conference rooms, a training room, office restrooms, large general clerical area, break rooms and plant restrooms and locker rooms.

320 x 255

Min: 22' 8", Max: 28' 7"

22’8” clear below the main beams at the eave to 28’7” clear below the main beam at the center

Exposed vinyl backed insulation supported with poultry wire

40' x 50'

Production Area - 67’/93’ x 25’

Warehouse - 40’ x 50’

10” painted steel H in production area
8” painted circular steel in the warehouse

Steel H

24 gauge Galvalume standing seam metal roof with exposed 4” vinyl backed insulation supported with poultry wire

Warehouse-40,800 sf at 6” concrete floor slab reinforced w/6x6x10/10 wire welded mesh over a polyethylene vapor barrier. Production Area 6,700 sf at 12” concrete floor slab reinforced with 2 layers of rebar over a polyethylene vapor barrier. 8,375 sf at 24” concrete floor slab reinforced with 2 layers of rebar over a polyethylene vapor barrier. 20,925 sf at 8” concrete floor slab reinforced w/6x6x10/10 wire welded fabric over a polyethylene vapor barrier.

26 gauge MSP pre-engineered metal panels with 4” exposed vinyl backed insulation protected by a 7’4” interior metal liner panel.

Metal halide throughout

The warehouse lighting is augmented by roof skylights.

Production Area
4–8’x9’ dock height loading doors with dock seals, bumper pads, manual load levelers

1–16’x16’ automatic roll up drive-in door

Warehouse
5–8’x9’ dock height automatic loading doors with automatic load levelers, dock seals & bumper pads

1–10’x10’ automatic roll up drive-in door

All doors are served by Rite-Hite Dok-Lok vehicle restraints

2–10’x10’ high speed automatic roll up drive-in doors provide access between the warehouse and production area

1 – 25 ton Progressive overhead bridge crane with 17’ underhook height, 60’ span and 100’ travel. This bridge rail could support another 10 ton overhead bridge crane.

Bridge crane rail supports remain in place that previously supported a 5 ton bridge crane and a 7.5 bridge crane with a 17’ underhook height, 60’ span and 125’ travel. The overhead bridge cranes have been removed; however, the crane rails remain in place.

Plant: 65 paved, marked and lighted spaces
Office: 24 paved, marked and lighted spaces

No

Piedmont Natural Gas - An extension is required to the property. There is a 4” line approximately 600’ away at the corner of Black & Decker Road and US Highway 301/Business I-95.

City

City

PWC-ElectriCities
Primary: 12.47 KV primary distribution line

Transformer: 1 – 2,500 KVA pad mounted transformer

Secondary: 1 – 2,000 amps General Electric Spectra Series interior switchgear at 480Y/277 volts, 3 phase, 4 wire

Combo
Plant: 12 Sterling gas fired ceiling mounted unit heaters. These were previously fired using an onsite propane tank which has been removed.

Office: 2 – 5 ton Carrier combination HVAC heat pumps

Yes - Plant: 7 – 15 tons Carrier electric fired air conditioning units. These were previously fired using an onsite propane tank which has been removed.

Office: 2 – 5 ton Carrier combination HVAC heat pumps

Yes - 100% wet system
The warehouse area has a design density of 0.45 gpm per square foot over the most remote 2,000 square feet. The production area has a design density of 0.60 gpm per square foot over the most remote 2,500 square feet.

Wall Mount - Wall mounted louvers and wall mounted centrifugal roof fans throughout the production area and warehouse

2 – 75 tons water cooled air compressors with air dryers, accumulation tanks and cooling towers which are scheduled to be removed. All air drops remain in place.

The warehouse is served by 8 Milcore double leaf smoke vents and 4 smoke curtains to form 4 – 10,000 square foot sections each with 2 vents per section.

Overall: 320’ x 255’
Warehouse: 160’ x 255’
Production Area: 167’ x 100’
67’ x 125’
93’ x 225’

Plastic Molding - Plastic injection molding
